24-port NWay Ethernet Switch User’s Guide
Using the Console Interface 93
♦ Software Update Mode Set to either network or SLIP.
Determines whether the configuration file should be obtained
through the Ethernet network or through the console port.
♦ TFTP Server Address The IP address of the TFTP server
where the configuration file is located. This entry is used only
if the Firmware Update is set to Enabled. If BOOTP Service
(see the IP Configuration screen) is set to Enabled, the
address will be obtained from the BOOTP server.
♦ Firmware Update Determines whether or not the Switch
will try to look for a runtime image file over the network. If
set to Disabled, none of the fields below have any effect.
♦ File Name The pathname of the runtime image file on your
TFTP server to be downloaded.
♦ Use Config File Toggle to Enabled to download config file
during reboot.
♦ Config File Name The name of the configuration file to be
downloaded.
System Utilities
The Utilities menu offers three system utility options, Ping Test,
Upload Configuration File, and Upload Switch History File.
The first function sends a Ping to test network connectivity
between the Switch and any other network device with an IP
address. The second function allows the user to specify a location of
a configuration file and send instructions to get it. The last function
allows the user to specify a location of a switch history file and send
instructions to get it.
