24-port NWay Ethernet Switch User’s Guide

Web-Based Network Management 165

Change Configuration File

To change a configuration file, fill the fields in above and then

click Apply.

The information is described as follows:

♦ Software Update Mode is Set to either Network or

SLIP. Determines whether the configuration file should be

obtained through the Ethernet network.or through the

console port.

♦ TFTP Server Address is The IP address of the TFTP

server where the configuration file is.

♦ File Download Determines whether or not the Switch

should download its configuration file the next time it is

booted.

♦ File Name The path and configuration name on the

TFTP server.
