24-port NWay Ethernet Switch User’s Guide
16 Identifying External Components
Figure 3-7. 100-BASE FX one-port module
♦ Front-panel module.
♦ Connects to 100BASE-FX devices at full or half-duplex.
♦ Supports multi-mode fiber-optic cable connections of up to 412
meters in half-duplex or 2 km in full-duplex mode.
100BASE-FX Fiber (MTRJ Type) Module
Figure 3-5. 100BASE-FX two-port module
♦ Front-panel module.
♦ Connects to 100BASE-FX devices at full or half-duplex.
♦ Supports multi-mode fiber-optic cable connections of up to 412
meters in half-duplex or 2 km in full-duplex mode.
Формат: Список
Формат: Список
Формат: Список
Удалено:
Удалено:
Удалено: fiber
Удалено: -
Удалено: Extends network
diameter
Удалено:
Удалено: 00
Удалено: Using the Console
Interface
