D-Link DES-2108/E [70/199] Configuration

24-port NWay Ethernet Switch User’s Guide

56 Using the Console Interface

To delete your user password:

1. Toggle the Delete field of the user you wish to remove to Yes.

2. Press APPLY to let the user deletion take effect.

Setting Up The Switch

This section will help prepare the Switch user by describing the

Configuration, Update Firmware and Configuration Files,

Save Changes, and System Utilities menus and their respective

sub-menus.

Configuration

Choose Configuration to access the first item on the DES-3225G

main menu. The following menu appears:
