24-port NWay Ethernet Switch User’s Guide
Using the Console Interface 111
♦ Multicast Group The IP address of the device that
maintains the multicast group.
♦ MAC Address The MAC address of the device that
maintains the multicast group.
♦ Queries(TX) The number of IGMP requests sent from the
router or server to individual network stations.
♦ Queries(RX) The number of IGMP requests received by the
________________________.
♦ Reports The number of notifications sent from each station
to the router, signifying that the station is still (or wants to
be) part of the multicast group.
♦ Ports The Switch ports supporting the selected multicast
group.
Switch History
The Network Monitoring menu allows the user to view the
Switch history. This works like a trap and event receiver except it
only captures trap/events generated by the Switch itself. For
example, the switch history includes when the system is rebooted,
when a console session is timed out, when a new link is
established, and when configuration is save to flash memory.
To display the Switch History screen, choose Network
Monitoring from the main menu and then choose Switch
History. The following screen appears:
