24-port NWay Ethernet Switch User’s Guide
12 Identifying External Components
3
3 I
DENTIFYING
E
XTERNAL
C
OMPONENTS
This chapter describes the front panel, rear panel, optional plug-in
modules, and LED indicators of the DES-3225G.
Front Panel
The front panel of the Switch consists of LED indicators, an RS-232
communication port, a slide-in module slot, two uplink ports, and
22 (10/100 Mbps) Ethernet/Fast Ethernet ports.
Figure 3-1. Front panel view of the Switch
♦ Comprehensive LED indicators display the status of the
switch and the network. A description of these LED
indicators follows (see the LED Indicators section below).
