24-port NWay Ethernet Switch User’s Guide

24 Switch Management

components, while the Switch can be manipulated to carry out

specific tasks.

Diagnostic (console) port (RS-232 DCE)

Out-of-band management requires connecting a terminal, such as a

VT-100 or a PC running terminal emulation program (such as

HyperTerminal, which is automatically installed with Microsoft

Windows) a to the RS-232 DCE console port of the Switch. Switch

management using the RS-232 DCE console port is called Local

Console Management to differentiate it from management done via

management platforms, such as D-View, HP OpenView, etc.

The console port is set for the following configuration:

◊ Baud rate: 9,600

◊ Data width: 8 bits

◊ Parity: none

◊ Stop bits: 1

◊ Flow Control None

Make sure the terminal or PC you are using to make this

connection is configured to match these settings.

If you are having problems making this connection on a PC,

make sure the emulation is set to VT-100 or ANSI. If you still

don’t see anything, try hitting <Ctrl> + r to refresh the screen.

IP Addresses and SNMP Community

Names

Each Switch has its own IP Address, which is used for

communication with an SNMP network manager or other TCP/IP
