24-port NWay Ethernet Switch User’s Guide
Switch Management 41
through. This selective forwarding feature based on VLAN criteria
is how VLANs segment networks. The key point being that Port 1
will only transmit on VLAN 2, because it’s Port VLAN ID number
is 2 (PVID=2).
Sharing Resources Across VLANs
Network resources such as printers and servers however, can be
shared across VLANs. This is achieved by setting up overlapping
VLANs as shown in the diagram below.
In the above example, there are three different VLANs and each
port can transmit packets on one of them according to their Port
VLAN ID (PVID). However, a port can receive packets on all
VLANs (VID) that it belongs to. The assignments are as follows:
Transmit on VLAN #
Port PVID
Port 1 2
Port 2 2
Port 3 2
