24-port NWay Ethernet Switch User’s Guide

22 Connecting The Switch

10BASE-T Device

For a 10BASE-T device, the Switch’s LED indicators should display

the following:

♦ 100M LED speed indicator is OFF.

♦ Link/Act indicator is ON.

100BASE-TX Device

For a 100BASE-TX device, the Switch’s LED indicators should

display the following:

♦ 100M LED speed indicator is ON.

♦ Link/Act is ON.
