24-port NWay Ethernet Switch User’s Guide
8 Unpacking and Setup
Installation
Use the following guidelines when choosing a place to install the
Switch:
♦ The surface must support at least 3 kg.
♦ The power outlet should be within 1.82 meters (6 feet) of the
device.
♦ Visually inspect the power cord and see that it is secured to
the AC power connector.
♦ Make sure that there is proper heat dissipation from and
adequate ventilation around the switch. Do not place heavy
objects on the switch.
Desktop or Shelf Installation
When installing the Switch on a desktop or shelf, the rubber feet
included with the device should first be attached. Attach these
cushioning feet on the bottom at each corner of the device. Allow
adequate space for ventilation between the device and the objects
around it.
