24-port NWay Ethernet Switch User’s Guide

Using the Console Interface 65

STP Port State and Status reflect the current conditions of the

port. They are read-only fields and cannot be changed.

Flow control is useful during periods of heavy network activity

when the Switch’s buffers can receive too much traffic and fill up

faster than the Switch can send the information. In such cases, the

Switch must intervene and tell the transmitting device to wait to

allow the information in the port buffer to be sent.

Configure Slot1 Module

This screen allows you to change the port state of the module in

slot 1 in the case when you would like to partition a port due to

excessive collision, or for observation, device repair, or security

reasons. Great caution, however, must be observed when

partitioning a port; you should make sure that the partitioned port

is not being used as the port to control or monitor the condition of

other devices.

To change the configuration of a port:

1. Select Configuration from the main menu and then choose

Configure Slot1 Module. The following screen appears:
