24-port NWay Ethernet Switch User’s Guide

Using the Console Interface 57

Figure 6-7. Configuration menu

You will need to change some settings to allow you to be able to

manage the Switch from an SNMP-based Network Management

System such as SNMP v1 or to be able to access the Switch using

the TELNET protocol. See the next chapter for Web-based network

management information.

Configure IP Address

The Switch needs to have a TCP/IP address assigned to it so that

the network management system or TELNET client can find it on

the network. The IP Configuration screen allows you to change

the settings for the two different interfaces used on the Switch: the

Ethernet interface used for in-band communication, and the SLIP

interface used over the console port for out-of-band communication.

Choose Configure IP Address to access the first item on the

Configuration menu. The following screen appears:

Figure 6-8. IP Configuration screen
