24-port NWay Ethernet Switch User’s Guide
108 Using the Console Interface
♦ TX Octets The number of good bytes sent from the
respective port.
♦ RX Octets The number of good bytes received. This also
includes local and dropped packets.
♦ Total RX The number of bytes received, good and bad.
♦ Unicast RX/Unicast TX The number of good unicast
frames received and sent. This includes dropped unicast
packets.
♦ Multicast RX/Multicast TX The number of good multicast
frames received and sent. This includes local and dropped
multicast packets.
♦ Broadcast RX/Broadcast TX The number of good
broadcast frames received and sent. This includes dropped
broadcast packets.
Browse Address Table
The Browse Address Table allows the user to view which Switch
port(s) a specific network device uses to communicate on the
network. You can sort this table by MAC address or port. This is
useful for viewing which ports one device is using, or which devices
are using one port.
To display the Browse Address Table, choose Network
Monitoring from the main menu and then choose Browse
Address Table. The following screen appears:
Удалено: Using the Console
Interface
