D-Link DES-2108/E [93/199] Configure mac address filtering

24-port NWay Ethernet Switch User’s Guide

Using the Console Interface 79

♦ Under the Destination Port heading a port number will be

displayed for each corresponding destination address.

♦ Under the Status heading, the status will be displayed for

each corresponding destination address. The status of the

MAC address can be ‘‘in use’’ or ‘‘not apply.’’ ‘‘Not apply’’

means the entry is conflicting with a higher priority function,

and may display ‘‘in use’’ at a later time.

By mapping a port to a destination MAC address, the switch can

permanently forward traffic to the specified device, even after long

periods of network inactivity or during times of network congestion.

To make a change to the Custom Forwarding Table, choose

either Add or Remove in the Action field. Then enter the MAC

Address, the Port number that permanently forwards traffic

from the specified device, regardless of the device’s network

activity or current network congestion, and press APPLY.

Configure MAC Address Filtering

The Custom Filtering Table contains filtering information

configured into the Switch by (local or network) management

specifying destination addresses which are not allowed to be

forwarded. You can use either source or destination addresses on

the Custom Filtering Table for network security purposes

thereby discarding unwanted addresses from the Forwarding

Table.

To access the Custom Filtering Table, select Configure

Filtering and Forwarding Table from the Configuration

menu. Then select Configure MAC Address Filtering from

the bottom of the Configure Filtering and Forwarding

table screen. The following screen appears:
