24-port NWay Ethernet Switch User’s Guide
6 Introduction
♦ Broadcast storm filtering.
♦ IGMP Multicast support.
Management
♦ RS-232 console port for out-of-band network management via
a console terminal or PC.
♦ Spanning Tree Algorithm Protocol for creation of alternative
backup paths and prevention of network loops.
♦ Fully configurable either in-band or out-of-band control via
SNMP based software.
♦ Flash memory for software upgrades. This can be done in-
band via BOOTP/TFTP or out-of-band via the console.
♦ Built-in SNMP management: Bridge MIB (RFC 1493),
RMON MIB (RFC 1757), and MIB-II (RFC 1213).
