24-port NWay Ethernet Switch User’s Guide
Web-Based Network Management 117
Clicking on this button causes an interactive view of the Switch’s
front panel to be shown in the top portion of the window.
Clicking on one of the Ports opens a configuration window for that
particular port.
The main page contains a list of buttons along the top of it labeled:
Configure Switch, Configure Management, Monitor, Reset
and Update, Save Changes, and Help. These are the major
categories for Switch management. Clicking on one of the first four
categories causes a list of options to appear in the left panel of the
main window.
All categories and options are explained below.
Configure Switch
This first category includes: IP Settings, Port Settings, Port
Mirroring, Switch Settings (Basic and Advanced), Filtering
and Forwarding Table (Configure, Permanent Address
Table, Permanent Multicast Filtering, and Multicast
Forwarding Table), Spanning Tree (STP Parameter and STP
Parameter & Port Settings), IGMP Filtering (IGMP Settings
and Configure 802.1Q IGMP), VLAN (Configure VLAN Mode,
Configure MAC-Based VLAN, and Configure 802.1Q VLAN),
and Trunk, as well as a number of related windows.
