24-port NWay Ethernet Switch User’s Guide

172 RJ-45 Pin Specification

9 RJ-45

PECIFICATION

When connecting the DES-3225G Switch to another switch, a

bridge or a hub, a modified crossover cable is necessary. Please

review these products for matching cable pin assignment.

The following diagram and table show the standard RJ-45

receptacle/connector and their pin assignments for the switch-to-

network adapter card connection, and the straight/ crossover cable

for the Switch-to-switch/hub/bridge connection.

Figure B-1. The standard RJ-45 receptacle/connector
