D-Link DES-2108/E [129/199] Anagement

24-port NWay Ethernet Switch User’s Guide

Web-Based Network Management 115

7 W

-B

ASED

ETWORK

ANAGEMENT

Introduction

The DES-3225G offers an embedded Web-based (hypertext)

interface allowing users to manage the Switch from anywhere on

the network through a standard browser such as Netscape

Navigator/Communicator or Microsoft Internet Explorer. The Web

browser acts as a universal access tool and can communicate

directly with the Switch using HTTP protocol. Your browser screen

may vary with the screen shots (pictures) in this guide.

NOTE: This Web-based Management Module does not

accept Chinese language input (or other languages

requiring 2 bytes per character).
