24-port NWay Ethernet Switch User’s Guide

52 Using the Console Interface

After establishing a User Account with Administrator-level

privileges, press Esc. twice. Then choose the Save Changes menu

(see below). Pressing any key will return to the main menu. You

are now ready to operate the Switch.

Save Changes

In order to retain any modifications made in the current session, it

is necessary to choose Save Changes from the main menu. The

following screen will appear to indicate your new settings have

been processed:

Figure 6-3. Save Changes screen
