24-port NWay Ethernet Switch User’s Guide
116 Web-Based Network Management
Getting Started
The first step in getting started in using web-based management
for your Switch is to secure a browser. A Web browser is a program
which allows a person to read hypertext, for example, Netscape
Navigator or Microsoft Internet Explorer. Follow the installation
instructions for the browser.
The second and last step is to configure the IP interface of the
Switch. This can be done manually through a console (see the
Configure IP Address section in the ‘‘Using The Console Interface’’
chapter).
Management
To begin managing your Switch simply run the browser you have
installed on your computer and open the IP address you have
defined for the device.
In the page that opens, click on the Login to DES-3225G Web-
based Management button:
This opens the main page in the management module.
The top of the main page has a button labeled Click Here to Load
Panel:
