24-port NWay Ethernet Switch User’s Guide
Using the Console Interface 99
The following SNMP Manager and Trap Manager Configuration
parameters can be set:
♦ Community String/SNMP Community String
Determines the SNMP community name to be included in the
trap request.
♦ Access Right Allows each community to be separately set
to either Read Only or Read/Write.
♦ Status Determines whether this community name entry is
Valid or Invalid. An entry can be deleted by changing its
status to Invalid.
♦ IP Address The IP address of the network management
station to receive the trap.
Switch Monitoring
The Switch allows you to keep statistics on the operation of each
port. The statistics obtained can be used to monitor the conditions
and general efficiency of the Switch.
Network Monitoring
The Network Monitoring menu offers four items, Traffic
Statistics, Browse Address Table, Browse IGMP Status, and
Switch History.
Choose Network Monitoring from the main menu. The following
menu appears:
