24-port NWay Ethernet Switch User’s Guide
104 Using the Console Interface
♦ Bytes Recv. The number of good bytes received. This also
includes local and dropped packets.
♦ Bytes Sent The number of good bytes sent from the respective
port.
♦ Frames Recv. The number of good frames received. This also
includes local and dropped packets.
♦ Frames Sent The number of good frames sent from the
respective port.
♦ Total Bytes Recv. The number of bytes received, good and
bad.
♦ Total Frames Recv. The number of frames received, good and
bad.
♦ Last Seen MAC The MAC address of the last device that sent
packets over this port.
Port Packet Error Statistics
To access the third item on the Traffic Statistics menu, choose
Port Packet Error Statistics. The following table appears:
