D-Link DES-2108/E [105/199] Configure trunk

24-port NWay Ethernet Switch User’s Guide

Using the Console Interface 91

Configure Trunk

The Switch allows you to configure the trunk.

Choose Configure Trunk to access the eleventh item on the

Configuration menu. The following screen appears:

Figure 6-33. Configure Trunk screen

The fields you can set are:

♦ Width Select between 2 to 8 ports in the first two entries for

this field. The third entry has a permanent setting of 2 ports.

♦ Group name Enter the desired group name.

♦ Status Toggle between Enabled and Disabled.

The Master column contains the _____________. Press APPLY to

let the changes take effect.

Удалено: Using the Console

Interface
