24-port NWay Ethernet Switch User’s Guide

58 Using the Console Interface

Each of the fields on this screen takes effect the next time the

system is restarted. Fields that can be set include:

♦ BOOTP Service Determines whether the Switch should

send out a BOOTP broadcast request when it is powered up.

The BOOTP protocol allows IP addresses, network masks,

and default gateways to be assigned on a central BOOTP

server; if this option is set the Switch will first look for a

BOOTP server to provide it with this information before

using the supplied settings.

♦ IP Address Determines the IP address used by the Switch

for receiving SNMP and TELNET communications. Should be

of the form xxx.xxx.xxx.xxx, where each xxx is a number

(represented in decimal) between 0 and 255. This address

should be a unique address on a network assigned to you by

the central Internet authorities. The same IP address is

shared by both the SLIP and Ethernet network interfaces.

♦ Subnet Mask Bitmask that determines the extent of the

subnet that the Switch is on. Should be of the form

xxx.xxx.xxx.xxx, where each xxx is a number (represented in

decimal) between 0 and 255. If no subnetting is being done,

the value should be 255.0.0.0 for a Class A network,

255.255.0.0 for a Class B network, and 255.255.255.0 for a

Class C network.

♦ Default Gateway IP address that determines where frames

with a destination outside the current subnet should be sent.

This is usually the address of a router or a host acting as an

IP gateway. If your network is not part of an internetwork, or

you do not want the Switch to be accessible outside your local

network, you can leave this field unchanged.
