24-port NWay Ethernet Switch User’s Guide

64 Using the Console Interface

Figure 6-12. Port Configuration screen

2. Specify the port in the Port(1-22,all) field.

3. In the State field, change the port state to Enabled or

Disabled.

4. In the Speed/Duplex field, select the desired setting: Auto,

100M/Full, 100M/Half, 10M/Full, or 10M/Half.

5. In the Flow Ctrl field, toggle On or Off. See below for a

further explanation of flow control. When Auto-Negotiation is

enabled, Flow Control capability exists but is not necessarily

functioning at that moment. Confirm that Flow Control is in

force by checking the Status field.

6. In the Priority field, select Normal, High or Low. The

Normal setting depends on the packet priority level. High

and Low refer to allowing a port either the first or last

priority.

7. In the first Broadcast Storm field, Rising Action, select

from Do Nothing, Blocking, or Blocking-Trap. Blocking

means only multicast and unicast packets can enter this

port. Blocking-Trap means only multicast and unicast

packets can enter this port and a trap will be sent. The upper

threshold for a Rising Action is 20%--this is the utilization

of the port’s bandwidth.

8. In the second Broadcast Storm field, Falling Action,

select from Do Nothing, Forwarding, or Forwarding-Trap.

Forwarding means broadcast packets will be sent to other

ports. Forwarding-Trap means broadcast packets will be sent

to other ports and a trap will be sent. The lower threshold for

a Falling Action is 10%--this is the utilization of the port’s

bandwidth.

9. Press CTRL+S to let the changes take effect.
