24-port NWay Ethernet Switch User’s Guide
120 Web-Based Network Management
2. Configure the Speed/Duplex setting for the port. Select
Auto-Negotiate to allow the port to select the best
transmission speed and duplex mode based on the
capabilities of the device at the other end. Select
100Mbps/Full for port operation at 100 Mbps and full
duplex. Select 100Mbps/Half for port operation at 100
Mbps and half duplex. Select 10Mbps/Full for port
operation at 10 Mbps and full duplex. Select 10Mbps/Half
for port operation at 10 Mbps and half duplex.
3. Configure the Flow Control setting for the port. Select
Enabled and use full duplex for IEEE 802.3x flow control.
Select Enabled and use half duplex for backpressure flow
control. Select Disabled for no flow control. Note that you
must reboot the Switch before a flow control change can
take effect.
4. Configure the Priority Queues setting for packets
passing through this port, using IEEE 802.1 tagging.
Select Low, High or Default. If the network is congested,
the switch handles packets with a higher priority before
those with lower priority.
5. Configure the Port Lock setting to prevent the port from
learning MAC addresses of new hosts. This will help keep
intruders off your network since any packet coming from
an unknown source will be dropped by the Switch, that is,
not added to your MAC Address Forwarding Table. Select
Enabled or Disabled.
6. Configure the Broadcast Storm Rising Action setting
from three choices: Do Nothing, Blocking, or Blocking-
Trap.
7. Configure the Broadcast Storm Falling Action setting
from three choices: Do Nothing, Forwarding, or
Forwarding-Trap.
