24-port NWay Ethernet Switch User’s Guide

Web-Based Network Management 129

To use the permanent multicast filtering function, check either the

Add to the table option button or the Delete from the table

option button, enter the MAC address of the device allowed to send

traffic in the MAC Address field, and then click Apply.

The information above is described as follows:

♦ Add to the table/Delete from the table Choose one of

the desired options to add or delete an entry from the

Permanent Multicast Filtering Table.

♦ MAC Address The Ethernet address of the Permanent

Multicast Filtering Table entry.
