24-port NWay Ethernet Switch User’s Guide

Web-Based Network Management 141

To add or delete a MAC-based VLAN table entry, check the desired

option in the first two lines of the window above, enter the

Current MAC-based VLAN in the field offered, and click Apply.

The MAC-based VLAN description must be the same as that used

in the port member group to enable the VLAN function. If the

source address is the same as the MAC address and the destination

is unknown, broadcast, or multicast, then the packet will be flooded

to all members of the VLAN port group.
