24-port NWay Ethernet Switch User’s Guide

Web-Based Network Management 153

Traffic in Bytes:

♦ Bytes Sent Counts the number of bytes successfully sent

from the port.

♦ Bytes Received Counts the total number of bytes (octets)

included in valid (readable) frames.

♦ Total Bytes Received Counts the total number of bytes

received on the port, whether in valid or invalid frames.

Traffic in Frames:

♦ Frames Sent Counts the total number of frames

transmitted from the port.

♦ Frames Received Counts all valid frames received on

the port.

♦ Total Frames Received Counts the number of frames

received on the port, whether they were valid or not.
