24-port NWay Ethernet Switch User’s Guide
Switch Management 27
♦ Link Change Event This trap is sent whenever the link of
a port changes from link up to link down or from link down to
link up.
♦ Port Partition This trap is sent whenever the port state
enters the partition mode (or automatic partitioning, port
disable) when more than thirty-two collisions occur while
transmitting at 10Mbps or more than sixty-four collisions
occur while transmitting at 100Mbps. .
♦ Broadcast Storm This trap is sent whenever the port
reaches the broadcast storm rising or falling threshold.
MIBs
Management information and counters are stored in the Switch in
the Management Information Base (MIB). The Switch uses the
standard MIB-II Management Information Base module.
Consequently, values for MIB objects can be retrieved from any
SNMP-based network manager software. In addition to the
standard MIB-II, the Switch also supports its own proprietary
enterprise MIB as an extended Management Information Base.
These MIBs may also be retrieved by specifying the MIB’s Object-
Identity (OID) at the network manager. MIB values can be either
read-only or read-write.
Read-only MIBs variables can be either constants that are
programmed into the Switch, or variables that change while the
Switch is in operation. Examples of read-only constants are the
number of ports and types of ports. Examples of read-only
variables are the statistics counters such as the number of errors
that have occurred, or how many kilobytes of data have been
received and forwarded through a port.
Удалено: The
Удалено: is known as
Удалено: MIB
Удалено: inside the Switch
Удалено: Using the Console
Interface
