24-port NWay Ethernet Switch User’s Guide
34 Switch Management
To alleviate network loop problems, STA can be applied as shown
in Figure 5-2. In this example, STA breaks the loop by blocking the
connection between Bridge 1 and 2. The decision to block a
particular connection is based on the STA calculation of the most
current Bridge and Port settings. Now, if Bridge 1 broadcasts a
packet to Bridge 3, then Bridge 3 will broadcast it to Bridge 2 and
the broadcast will end there.
STA setup can be somewhat complex. Therefore, you are advised to
keep the default factory settings and STA will automatically assign
root bridges/ports and block loop connections. However, if you need
to customize the STA parameters, refer to Table 5-1.
Figure 5-1. Before Applying the STA Rules
