Daikin RXYQ16M7W1B [113/344] Demand operation
![Daikin RXYQ16M7W1B [113/344] Demand operation](/views2/1707433/page113/bg71.png)
Other Control SiE39-404
102 Function
• To inhibit the slave unit 2 from operating → Set
setting mode 2 from No. 40 to No. 2.
(Procedure)
(1) Press and hold the MODE button (BS1) for 5 sec. or
more.
(2) Press the SET button (BS2) 40 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) once.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
∗
• In the case of multi-outdoor-unit system, “Inhibition of operation” is not set with each
compressor individually.
• In the case of multi-outdoor-unit system, when the above “Inhibition of operation” is set,
outdoor unit rotation is not functional.
5.3 Demand Operation
In order to save the power consumption, the capacity of outdoor unit is saved with control
forcibly by using “Demand 1 Setting” or “Demand 2 Setting”.
To operate the unit with this mode, additional setting of “Continuous Demand Setting” or
external input by external control adapter is required.
[Demand 1 setting]
[Demand 2 setting]
H Other protection control functions have precedence over the above operation.
5.4 Heating operation prohibition
Heating operation is prohibited above 24°C ambient temperature.
LED display (
7
:ON
7
:OFF
9
:Blink)
H1P
---
H7P
(Factory set)
7
777777
77
7
77
777
7
777779
7
777797
7
777777
77
777
7777
Note : Reset the power supply during the outdoor unit is stopping to cancel the
automatic backup operation forcibly.
Setting Standard for upper limit of power consumption
Demand 1 setting 1 Approx. 60%
Demand 1 setting 2 (factory setting) Approx. 70%
Demand 1 setting 3 Approx. 80%
Setting Standard for upper limit of power consumption
Demand 2 setting 2 (factory setting) Approx. 40%
