Troubleshooting by Indication on the Remote Controller SiE39-404
196 Troubleshooting
∗1 Coil check method for the moving part of the electronic expansion valve
Disconnect the electronic expansion valve from the PC board and check the continuity between
the connector pins.
(Normal)
: Continuity Approx. 300Ω
{ : Continuity Approx. 150Ω
× : No continuity
Pin No. 1. White 2. Yellow 3. Orange 4. Blue 5. Red 6. Brown
1. White × × { ×
2. Yellow × × {
3. Orange × { ×
4. Blue × {
5. Red ×
6. Brown
