SiE39-404 Precautions for New Refrigerant (R410)
Precautions for New Refrigerant (R410) 321
1.3 Service Tools
R410A is used under higher working pressure, compared to previous refrigerants (R22,R407C).
Furthermore, the refrigerating machine oil has been changed from Suniso oil to Ether oil, and if
oil mixing is occurred, sludge results in the refrigerants and causes other problems. Therefore,
gauge manifolds and charge hoses that are used with a previous refrigerant (R22,R407C) can
not be used for products that use new refrigerants.
Be sure to use dedicated tools and devices.
Tool compatibility
As for the charge mouthpiece and packing, 1/2UNF20 is necessary for mouthpiece size of
charge hose.
Copper tube material and thickness
* O: Soft (Annealed)
H: Hard (Drawn)
Tool
Compatibility
Reasons for changeHFC HCFC
R410A R407C R22
Gauge manifold
Charge hose
5
2Do not use the same tools for R22 and
R410A.
2Thread specification differs for R410A
and R407C.
Charging cylinder 5 { 2Weighting instrument used for HFCs.
Gas detector { 5 2The same tool can be used for HFCs.
Vacuum pump
(pump with reverse flow
preventive function)
{
2To use existing pump for HFCs,
vacuum pump adaptor must be
installed.
Weighting instrument {
Charge mouthpiece 5
2Seal material is different between R22
and HFCs.
2Thread specification is different
between R410A and others.
Flaring tool (Clutch type) { 2For R410A, flare gauge is necessary.
Torque wrench { 2Torque-up for 1/2 and 5/8
Pipe cutter {
Pipe expander {
Pipe bender {
Pipe assembling oil 5
2Due to refrigerating machine oil
change. (No Suniso oil can be used.)
Refrigerant recovery
device
Check your recovery device.
Refrigerant piping See the chart below.
2Only φ19.1 is changed to 1/2H material
while the previous material is "O".
Pipe size
φ6.4
φ9.5
φ12.7
φ15.9
φ19.1
φ22.2
φ25.4
φ28.6
φ31.8
φ38.1
φ44.5
Ve-up
R407C
Material
O
O
O
O
O
1/2H
1/2H
1/2H
1/2H
1/2H
1/2H
Ve-up
II
R410A
Material
O
O
O
O
1/2H
1/2H
1/2H
1/2H
1/2H
1/2H
1/2H
Thickness
[mm]
0.8
0.8
0.8
1.0
1.0
1.0
1.0
1.0
1.2
1.4
1.6
Thickness
[mm]
0.8
0.8
0.8
1.0
1.0
1.0
1.0
1.0
1.1
1.4
1.6
