Field Setting SiE39-404
126 Test Operation
Setting of Air Flow Direction Adjustment Range
Make the following air flow direction setting according to the respective purpose.
Setting Table
Air flow rate switching at discharge grille for field air flow rate switching
When the optional parts (high performance filter, etc.) is installed, sets to change fan speed for
securing air flow rate.
Follow the instruction manual for the optional parts to enter the setting numbers.
Setting of the static pressure selection (for FXDQ model)
Mode No. First Code No. Second Code No. Setting
13 (23) 4 01 Upward (Draft prevention)
02 Standard
03 Downward (Ceiling soiling
prevention)
Model No. First Code No. Second Code No. External static pressure
13 (23) 5
01 Standard (15Pa)
02 High static pressure (44Pa)
