Daikin RXYQ16M7W1B [181/344] The system operates for malfunction codes indicated in black squares however be sure to check and repair
![Daikin RXYQ16M7W1B [181/344] The system operates for malfunction codes indicated in black squares however be sure to check and repair](/views2/1707433/page181/bgb5.png)
Troubleshooting by Remote Controller SiE39-404
170 Troubleshooting
Outdoor
Unit
LA 999Malfunction of power unit —
LC 999Malfunction of transmission between inverter and
control PC board
213
P1 999Inverter over-ripple protection 215
P4 999Malfunction of inverter radiating fin temperature rise
sensor
216
System
U0 879Low pressure drop due to refrigerant shortage or
electronic expansion valve failure
217
U1 999Reverse phase / open phase 218
U2 999Power supply insufficient or instantaneous failure 219
U3 999Check operation is not conducted. 221
U4 999Malfunction of transmission between indoor and
outdoor units
222
U5 999Malfunction of transmission between remote
controller and indoor unit
224
U5 787Failure of remote controller PC board or setting
during control by remote controller
224
U7 999Malfunction of transmission between outdoor units 225
U8 997Malfunction of transmission between master and
slave remote controllers (malfunction of slave remote
controller)
227
U9 999Malfunction of transmission between indoor unit and
outdoor unit in the same system
228
UA 999Excessive number of indoor units etc. 230
UC 888Address duplication of central remote controller 231
UE 999Malfunction of transmission between central remote
controller and indoor unit
232
236
242
UF 999Refrigerant system not set, incompatible wiring /
piping
234
UH 999Malfunction of system, refrigerant system address
undefined
235
Centralized
Control
and
Schedule
Timer
M1 8 or 79 9PC board defect 237
244
M8 8 or 79 9Malfunction of transmission between optional
controllers for centralized control
238
245
MA 8 or 79 9Improper combination of optional controllers for
centralized control
239
246
MC 8 or 79 9Address duplication, improper setting 241
248
Heat
Reclaim
Ventilation
64 879Indoor unit’s air thermistor error —
65 879Outside air thermistor error —
68 879 —
6A 879Damper system alarm —
6A 999Damper system + thermistor error —
6F 879Malfunction of simple remote controller —
6H 879Malfunction of door switch or connector —
94 999Internal transmission error —
Malfunction
code
Operation
lamp
Inspection
display
Unit No. Malfunction contents Page
Referred
The system operates for malfunction codes indicated in black squares, however, be sure to check and repair.
