SiE39-404 Selection of Pipe Size, Joints and Header
Appendix 307
6.1.3 How to select the REFNET header
When connecting the indoor unit larger than 250 or more, use with KHRP26M33T,M72T to
upper stream side.
(Do not connect downstream side)
Select the proper REFNET Header using the following table based on the total capacity index of
indoor units installed after the header.
6.1.4 Piping between the REFNET Joints
Select the proper pipe size using the following table based on the total capacity index of indoor
units connected downstream.
Connection piping size should not exceed the refrigerant piping size selected by "the model with
combination units".
6.1.5 Piping between the REFNET Joints and indoor unit
Pipe size for direct connection to indoor unit must be the same as the connection size of indoor
unit.
Total capacity index of indoor units REFNET Header (Kit Name)
<200 KHRP26M22H (Max.4 Branches)
<290 KHRP26M33H (Max.8 Branches)
≥290 KHRP26M72H (Max.8 Branches)
Total capacity index of indoor units Gas Liquid
<200 φ15.9
φ9.5
≥200~<290 φ22.2
≥290~<420 φ28.6 φ12.7
≥420 φ28.6 φ15.9
Connection pipe size of indoor unit.
Indoor Units Gas Liquid
20 · 25 · 32 · 40 · 50 Type φ12.7 φ6.4
63 · 80 · 100 · 125 Type φ15.9
φ9.5200 Type φ19.1
250 Type φ22.2
