SiE39-404 Troubleshooting by Remote Controller
Troubleshooting 165
1.4 Operation of The Remote Controller’s Inspection / Test
Operation Button
Indoor unit system code
Type
Unit
Malfunction code
Inspection
0
L 0
(V2775)
Normal display (No display)
Push the button.
Inspection/test
operation
Unit 0
Malfunction code L 0
Inspection
Push the button.
Inspection mode
Inspection/test
operation
0 7 1
F C J
Inspection/test
operation
Push the button.
Push the button.
– – –
A A 1
Indoor unit model code display
Indoor unit model code display
Inspection/test
operation
Test operation mode
Test oper
ation
Push the button.
Inspection/test
operation
Outdoor model code
VRV II
High COP type R407C L Series
VRV Heat Recovery Series
R407C VRV PLUSSeries
VRV System Inverter K Series
Display
A A 1
A A 3
A 9 2
A A 5
A A A
Model
RSXYP
RXYP
RSEYP
RSXYP-L
RXYQ-M
Indoor unit type code
System classification
(VAV indoor unit)
Outdoor air processing unit
Standard indoor unit
New ceilling suspended cassette
Product classification
VRV system
VRV system
VRV system
VRV system
Display
1
2
F
H
Display
028
071
Example model
FXCQ25
FXFQ63
Example of capacity code display
Capacity code
Indoor unit system code
Indoor unit type code
Progression code
0 7 1...
F...
C...
J...
Malfunction code blinks when a malfunction occurs.
Model
FXAQ
FXCQ
FXKQ
FXFQ
FXHQ
FXSQ
FXLQ
FXMQ
FXNQ
FXZQ
FXDQ
FXUQ
Type
Wall mounted
Double flow
Corner
Multi flow
Ceiling suspended
Built-in
Floor standing
Concealed ceiling duct
Concealed floor standing type
Multi flow 600×600
Slim Ceilling mounted duct
New ceilling suspended cassette
Display
A
C
E
F
H
J
L
P
L
6
3
5
