SiE39-404 Specifications
Specifications 47
Outdoor Air Processing Unit
Notes:
H1. Specifications are based on the following conditions:
· Cooling: Outdoor temp. of 33°CDB, 28°CWB (68% RH). and discharge temp. of 18°CDB
· Heating: Outdoor temp. of 0°CDB, -2.9°CWB (50% RH). and discharge temp. of 25°CDB
· Equivalent reference piping length: 7.5m (0m Horizontal)
· At 220V
H2. Air intake filter is not supplied, so be sure to install the optional long-life filter or high-efficiency filter.
Prease mount it in the duct system of the suction side. Select its colorimetric method (gravity method)
50% or more.
H3. Anechoic chamber conversion value, measured at a point 1.5m downward from the unit center.
These values (measured at 220V) are normally somewhat higher during actual operation as a result of
ambient conditions.
H4. Valves measured at 220 V.
H5. Within the range that the total capacity of indoor units is 50 to 100%, it is possible to connect to the
outdoor unit.
H6. It is not possible to connect to the 5 HP outdoor unit. Not available for Heat Recovery type and VRV II-S
series.
· This equipment cannot be incorporated into the refrigerant piping system or remote group control of the
VRV II system.
Model FXMQ125MFV1 FXMQ200MFV1 FXMQ250MFV1
H1 Cooling Capacity
kcal/h 12,000 19,300 24,100
Btu/h 47,800 76,500 95,600
kW 14.0 22.4 28.0
H1 Heating Capacity
kcal/h 7,700 12,000 15,000
Btu/h 30,000 47,500 59,400
kW 8.9 13.9 17.4
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 470×744×1,100 470×1,380×1,100 470×1,380×1,100
Coil (Cross
Fin Coil)
Rows×Stages×Fin
Pitch
mm 3×26×2.0 3×26×2.0 3×26×2.0
Face Area m² 0.28 0.65 0.65
Fan
Model D13/4G2DA1 D13/4G2DA1 D13/4G2DA1
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output ×
Number of Units
W 380×1 380×1 380×1
Air Flow Rate (H/L)
m³/min182835
cfm 635 988 1,236
External Static
Pressure H4
Pa 185 225 205
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber
Air Filter H2 H2 H2
Piping
Connections
Liquid Pipes
9.5mm
(Flare Connection)
9.5mm
(Flare Connection)
9.5mm
(Flare Connection)
Gas Pipes
15.9mm
(Flare Connection)
19.1mm
(Brazing Connection)
22.2mm
(Brazing Connection)
Drain Pipe (mm) PS1B (female thread) PS1B (female thread) PS1B (female thread)
Machine Weight (Mass) kg 86 123 123
Sound Level (220V) H3,H4 dBA 42 47 47
Safety Devices
Fuse
Thermal Protector
for Fan Motor
Fuse
Thermal Protector
for Fan Motor
Fuse
Thermal Protector
for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Standard Accessories
Operation Manual, Installation Manual,
Sealing Pads, Screws, Clamps.
Operation Manual, Installation Manual,
Sealing Pads, Connection Pipes,
Screws, Clamps.
Operation Manual, Installation Manual,
Sealing Pads, Connection Pipes,
Screws, Clamps.
Connectable Outdoor Units H5,H6 RXYQ8~48MY1B RXYQ8~48MY1B RXYQ10~48MY1B
Drawing No. 3D046147A 3D046147A 3D046147A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
