SiE39-404 Specifications
Specifications 13
Notes:
H1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference
: 0m.
Model Name (Combination Unit) RXYQ18MY1B RXYQ20MY1B
Model Name (Independent Unit) RXYQ8MY1B+RXYQ10MY1B RXYQ10MY1B+RXYQ10MY1B
H1 Cooling Capacity (19.5°CWB)
kcal / h 45,000 50,000
Btu / h 178,000 197,000
kW 52.0 57.8
H2 Cooling Capacity (19.0°CWB) kW 50.4 56.0
H3 Heating Capacity
kcal / h 48,500 54,000
Btu / h 193,000 216,000
kW 56.5 63.0
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm (1600×930×765)+(1600×930×765) (1600×930×765)+(1600×930×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (13.72+10.47)×2 (13.72+10.47)×2
Number of Revolutions r.p.m (6480, 2900)×2 (6480, 2900)×2
Motor Output×Number
of Units
kW (1.2+4.5)+(2.7+4.5) (2.7+4.5)×2
Starting Method Soft start Soft start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×2 0.75×2
Air Flow Rate m³/min 175+180 180+180
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ15.9 (Brazing Connection) φ15.9 (Brazing Connection)
Gas Pipe mm φ28.6 (Brazing Connection) φ28.6 (Brazing Connection)
Oil Equalizing Pipe mm φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Machine Weight (Mass) kg 230+230 230+230
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 7~100 7~100
Refrigerant
Refrigerant Name R410A R410A
Charge kg 8.6+9.6 9.6+9.6
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator
Oil
Synthetic (ether) oil Synthetic (ether) oil
Charge Volume L (1.9+1.6)+(1.9+1.6) (1.9+1.6)+(1.9+1.6)
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. 4D038965B, 4D038966B 4D038966B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
