SiE39-404 List of Electrical and Functional Parts
Appendix 293
3. List of Electrical and Functional Parts
3.1 Outdoor Unit
3.1.1 RXYQ5~16MY1B
*
Valve in ( ) are for RXYQ5MY1B
Item Name Symbol
Model
RXYQ5MY1B RXYQ8MY1B RXYQ10MY1B
Compressor Inverter Type M1C JT1FCVDKYR
3.2kW
JT1FCVDKTYR
1.2kW
JT1FCVDKTYR
2.7kW
Output
STD.1 Type M2C — JT170FCKYE
4.5kW
JT170FCKYE
4.5kW
Output
STD.2 Type M3C —
Output
Crankcase heater (INV) E1HC 240V 33W
Crankcase heater (STD.1) E2HC — 240V 33W
Crankcase heater (STD.2) E3HC —
OC protection device for STD
compressor
—— 15A
Fan motor Motor M1F 0.35kw 0.75kw
OC protection device — 1.6A 3.2A
Functional parts Electronic expansion
valve (Main)
Cooling Y1E 1400pls 0pls
Heating PI control
Electronic expansion
valve (Subcool)
Cooling Y2E — PI control
Heating 0pls
Solenoid valve (Hot gas) Y1S TEV1620DQ2
Solenoid valve (External multi oil) Y2S — TEV1620DQ2
Solenoid valve (Receiver gas
discharge)
Y3S (Y2S) VPV-603D
Solenoid valve (Non-operating
unit liquid pipe close)
Y4S — VPV-803DXF
4 way valve Y5S (Y3S) VHV0310 VT40110
Solenoid valve (Injection) (Y4S) TEV1620DQ2 —
Pressure-
related parts
Pressure switch (INV) S1PH PS80 ON : 3.8+0/-0.15MPa OFF : 2.85±0.15MPa
Pressure switch (STD1) S2PH — PS80
ON : 3.8+0/-0.15MPa
OFF : 2.85±0.15MPa
Pressure switch (STD2) S3PH —
Fusible plug — FPGD-3D 70 to 75°C
Pressure sensor (HP) S1NPH PS8051A 0 to 4.15MPa
Pressure sensor (LP) S1NPL PS8051A -0.1 to 1.7MPa
Thermistor INV
PCB
For fin R1T 3.5 to 360Ω
Main
PCB
For outdoor air R1T 3.5 to 360Ω
For suction pipe R2T 3.5 to 360Ω
For discharge pipe
(INV)
R31T
(R3T)
3.5 to 400Ω
For discharge pipe
(STD.1)
R32T 3.5 to 400Ω
For discharge pipe
(STD.2)
R33T 3.5 to 400Ω
For heat exchanger R4T 3.5 to 360Ω
For subcooling heat
exchanger
R5T 3.5 to 360Ω
For receiver liquid pipe R6T 3.5 to 360Ω
For oil equalizing pipe R7T 3.5 to 360Ω
Others Fuse (A1P) F1, 2U 250VAC 10A Class B
