List of Electrical and Functional Parts SiE39-404
294 Appendix
Item Name Symbol
Model
RXYQ12MY1B RXYQ14MY1B RXYQ16MY1B
Compressor Inverter Type M1C JT1FCVDKTYR
4.2kW
JT1FCVDKTYR
2.0kW
JT1FCVDKTYR
3.0kW
Output
STD.1 Type M2C JT170FCKYE
4.5kW
JT170FCKYE
4.5kW
JT170FCKYE
4.5kW
Output
STD.2 Type M3C — JT170FCKYE
4.5kW
JT170FCKYE
4.5kW
Output
Crankcase heater (INV) E1HC 240V 33W
Crankcase heater (STD.1) E2HC 240V 33W
Crankcase heater (STD.2) E3HC — 240V 33W
OC protection device for STD
compressor
—15A
Fan motor Motor M1F 0.75kw
OC protection device — 3.2A
Functional parts Electronic expansion
valve (Main)
Cooling Y1E 0pls
Heating PI control
Electronic expansion
valve (Subcool)
Cooling Y2E PI control
Heating 0pls
Solenoid valve (Hot gas) Y1S TEV1620DQ2
Solenoid valve (External multi oil) Y2S TEV1620DQ2
Solenoid valve (Receiver gas
discharge)
Y3S VPV-603D
Solenoid valve (Non-operating
unit liquid pipe close)
Y4S VPV-803DXF
4 way valve Y5S VT40110 VT60100
Pressure-
related parts
Pressure switch (INV) S1PH PS80 ON : 3.8+0/-0.15MPa OFF : 2.85±0.15MPa
Pressure switch (STD1) S2PH PS80 ON : 3.8+0/-0.15MPa OFF : 2.85±0.15MPa
Pressure switch (STD2) S3PH — PS80
ON : 3.8+0/-0.15MPa
OFF : 2.85±0.15MPa
Fusible plug — FPGD-3D 70 to 75°c
Pressure sensor (HP) S1NPH PS8051A 0 to 4.15MPa
Pressure sensor (LP) S1NPL PS8051A -0.1 to 1.7MPa
Thermistor INV
PCB
For fin R1T 3.5 to 360Ω
Main
PCB
For outdoor air R1T 3.5 to 360Ω
For suction pipe R2T 3.5 to 360Ω
For discharge pipe
(INV)
R31T 3.5 to 400Ω
For discharge pipe
(STD.1)
R32T 3.5 to 400Ω
For discharge pipe
(STD.2)
R33T 3.5 to 400Ω
For heat exchanger R4T 3.5 to 360Ω
For subcooling heat
exchanger
R5T 3.5 to 360Ω
For receiver liquid pipe R6T 3.5 to 360Ω
For equalizing pipe R7T 3.5 to 360Ω
Others Fuse (A1P) F1, 2U 250VAC 10A Class B
