Wiring Diagrams for Reference SiE39-404
286 Appendix
FXLQ20M / 25M / 32M / 40M / 50M / 63MVE
FXNQ20M / 25M / 32M / 40M / 50M / 63MVE
A1P
C1P
F1U
HAP
K1R-K3R
M1F
Q1M
R1T
R2T•R3T
T1R
X1M
Printed circuit board
Capacitor (M1F)
Fuse (훾, 5A, 250V)
Light emitting diode
(Service monitor-green)
Magnetic relay (M1F)
Motor (Indoor fan)
Thermo switch
(M1F embedded)
Thermistor (Air)
Thermistor (Coil)
Transformer (220-240V/22V)
Ter min al block (Power)
Indoor unit
X2M
Y1E
Ter min al block (Control
Electronic expansion valve
R1T
SS1
Thermistor (Air)
Selector switch (Main/sub)
Wired remote control
X18A
Connector (Wiring adaptor for
electorical appendices)
Connector for optional parts
Notes:
1. : Terminal block, , : Connector, :Terminal
2. : Field wiring
3. In case using central remote control, connect it to the unit in
accordance with the attached instruction manual.
4. When connection the input wires from outside, forced off or on/off
control operation can be selected by remote control, in details,
refer to the installation manual attached the unit.
5. Symbolsshowsas follows. (PNK: pink, WHT: white, YLW: yellow,
ORG: orange, BLU: blue, BLK: black, RED: red, BRN: b
rown)
6. Use copper conductors only.
Note: 3
Transmission wiring
central remote control
Note: 4
Input from outside
Electric partsbox
Power supply
Wired remote control
(Optional accessory)
220-240V
~
50Hz
220V
~
60Hz
3D039826A
