Model Selection SiE39-404
6 General Information
4. Model Selection
VRV II Heat Pump Series
Connectable indoor units number and capacity
HP 5HP 8HP 10HP 12HP 14HP 16HP
System name RXYQ5M RXYQ8M RXYQ10M RXYQ12M RXYQ14M RXYQ16M
Outdoor unit 1 RXYQ5M RXYQ8M RXYQ10M RXYQ12M RXYQ14M RXYQ16M
Outdoor unit 2 – – – – – –
Outdoor unit 3 – – – – – –
Total number of connectable indoor units 8 13 16 19 20 20
Total capacity of connectable indoor units (kW)
7.0~18.2 11.2~29.1 14.0~36.4 16.8~43.6 20.0~52.0 22.5~58.5
HP 18HP 20HP 22HP 24HP 26HP 28HP
System name RXYQ18M RXYQ20M RXYQ22M RXYQ24M RXYQ26M RXYQ28M
Outdoor unit 1 RXYQ8M RXYQ10M RXYQ10M RXYQ10M RXYQ10M RXYQ12M
Outdoor unit 2 RXYQ10M RXYQ10M RXYQ12M RXYQ14M RXYQ16M RXYQ16M
Outdoor unit 3 – – – – – –
Total number of connectable indoor units 20 20 22 32 32 32
Total capacity of connectable indoor units (kW)
25.2~65.5 28.0~72.8 30.8~80.0 34.0~88.4 36.5~94.9 39.3~102.1
HP 30HP 32HP 34HP 36HP 38HP 40HP
System name RXYQ30M RXYQ32M RXYQ34M RXYQ36M RXYQ38M RXYQ40M
Outdoor unit 1 RXYQ14M RXYQ16M RXYQ10M RXYQ10M RXYQ10M RXYQ10M
Outdoor unit 2 RXYQ16M RXYQ16M RXYQ10M RXYQ10M RXYQ12M RXYQ14M
Outdoor unit 3 – – RXYQ14M RXYQ16M RXYQ16M RXYQ16M
Total number of connectable indoor units 32 32 34 36 38 40
Total capacity of connectable indoor units (kW)
42.5~110.5 45.0~117.0 48.0~124.8 50.5~131.3 53.3~138.5 56.5~146.9
HP 42HP 44HP 46HP 48HP
System name RXYQ42M RXYQ44M RXYQ46M RXYQ48M
Outdoor unit 1 RXYQ10M RXYQ12M RXYQ14M RXYQ16M
Outdoor unit 2 RXYQ16M RXYQ16M RXYQ16M RXYQ16M
Outdoor unit 3 RXYQ16M RXYQ16M RXYQ16M RXYQ16M
Total number of connectable indoor units 40 40 40 40
Total capacity of connectable indoor units (kW)
59.0~153.4 61.8~160.6 65.0~169.0 67.5~175.5
