SiE39-404 Wiring Diagrams for Reference
Appendix 289
FXLQ20MH / 25MH / 32MH / 40MH / 50MHV1
A1P
C1R
H1P
H2P
M1F
Q1M
R1T
R2T
RyF1, 3, 4
SS1
T1R
X1M
X2M
RC
TC
Printed circuit board
Capacitor (M1F)
Light emitting diode
(Service monitor green)
Light emitting diode
(Service monitor green)
Motor (Indoor fan)
Thermo switch (135°)
(M1F embedded)
Thermistor (Air)
Thermistor (Coil)
Magnetic relay (M1F)
Selector switch
(Emergency)
Transformer (220-240V/22V)
Terminal block (Power)
Terminal block (Control)
Signal receiver circuit
Signal transmission circuit
X30A
X33A
X35A
Connector
(Interface ad
aptor for
sky a
ir series)
Connector
(Adaptor for wiring)
Connector
(Group control adaptor)
Connector for optional parts
Notes:
1. : Terminal, : Connector, : Field wiring
2. Remote control model variesaccording to the combination
system, confirm engineering materialsand catalogs, etc. before
connecting.
3. : Showsshort circuit connector.
4. Symbolsshowsas follows: RED: red, WHT: white,
BLK: black, ORG: orange, BRN: brown, BLU: blue, YLW: yellow.
5. Confirm the method of setting the s
elector switch (
SS1, SS2) of
wired remote control and infrared remote control by installation
manual and engineering data, etc.
6. The BEV unit showsan outline, please refer to a wiring diagram
of BEV unit pasting in detail.
7. In case using central remote control, connect it to the unit in
accordance with the attached installation manual.
Power supply
RC TC
Wired remote control
(Optional accessory)
Control box
Emg. Norm.
220-240V
~
50
Indoor unit
R1T
SS1
Thermistor (Air)
Selector switch (Main/sub)
Wired remote control
Note: 6
BEV unit
3D046787A
