SiE39-404 Specifications
Specifications 19
Notes:
H1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference
: 0m.
Model Name (Combination Unit) RXYQ42MY1B RXYQ44MY1B
Model Name (Independent Unit) RXYQ10MY1B+RXYQ16MY1B+RXYQ16MY1B RXYQ12MY1B+RXYQ16MY1B+RXYQ16MY1B
H1 Cooling Capacity (19.5°CWB)
kcal / h 105,000 110,000
Btu / h 413,000 432,000
kW 121 127
H2 Cooling Capacity (19.0°CWB) kW 117 123
H3 Heating Capacity
kcal / h 113,000 118,000
Btu / h 450,000 470,000
kW 132 138
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm (1600×930×765)+(1600×1240×765)+(1600×1240×765) (1600×1240×765)+(1600×1240×765)+(1600×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (13.72+10.47)+(13.72+10.47+10.47)×2 (13.72+10.47)+(13.72+10.47+10.47)×2
Number of Revolutions r.p.m (6480, 2900), (6480, 2900×2)×2 (6480, 2900), (6480, 2900×2)×2
Motor Output×Number
of Units
kW (2.7+4.5)+(3.0+4.5+4.5)×2 (4.2+4.5)+(3.0+4.5+4.5)×2
Starting Method Soft start Soft start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×3 0.75×3
Air Flow Rate m³/min 180+210+210 210+210+210
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ19.1 (Brazing Connection) φ19.1 (Brazing Connection)
Gas Pipe mm φ41.3 (Brazing Connection) φ41.3 (Brazing Connection)
Oil Equalizing Pipe mm φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Machine Weight (Mass) kg 230+325+325 281+325+325
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 4~100 4~100
Refrigerant
Refrigerant Name R410A R410A
Charge kg 9.6+14.4+14.4 11.4+14.4+14.4
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator
Oil
Synthetic (ether) oil Synthetic (ether) oil
Charge Volume L (1.9+1.6)+(1.9+1.6+1.6)+(1.9+1.6+1.6) (1.9+1.6)+(1.9+1.6+1.6)+(1.9+1.6+1.6)
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. 4D038966B, 4D038969C 4D038967C, 4D038969C
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
