Specifications SiE39-404
10 Specifications
1. Specifications
1.1 Outdoor Units
Notes:
H1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
H3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference
: 0m.
Model Name RXYQ5MY1B RXYQ8MY1B
H1 Cooling Capacity (19.5°CWB)
kcal / h 12,500 20,000
Btu / h 49,500 78,900
kW 14.5 23.1
H2 Cooling Capacity (19.0°CWB) kW 14.0 22.4
H3 Heating Capacity
kcal / h 13,800 21,500
Btu / h 54,600 85,400
kW 16.0 25.0
Casing Color Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Dimensions: (H×W×D) mm 1600×635×765 1600×930×765
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 13.72 13.72+10.47
Number of Revolutions r.p.m 6480 6480, 2900
Motor Output×Number
of Units
kW 3.2×1 (1.2+4.5)×1
Starting Method Soft start Soft start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.35×1 0.75×1
Air Flow Rate m³/min 75 175
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipe mm φ15.9 (Flare Connection) φ19.1 (Brazing Connection)
Oil Equalizing Pipe mm — —
Machine Weight (Mass) kg 160 230
Safety Devices
High Pressure Switch, Fan Driver Overload Protector,
Inverter Overload Protector, Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 24~100 14~100
Refrigerant
Refrigerant Name R410A R410A
Charge kg 5.6 8.6
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator
Oil
Synthetic (ether) oil Synthetic (ether) oil
Charge Volume L 1.2 1.9+1.6
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. 4D038964B 4D038965B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
