Field Setting SiE39-404
132 Test Operation
3.2 Field Setting from Outdoor Unit
3.2.1 Field Setting from Outdoor Unit
Setting by dip switches
The following field settings are made by dip switches on PC board.
Refer “DS1-4, DS2-1~4 setting detail” on next page.
Dipswitch
Setting item Description
No. Setting
DS1-1
ON
Cool / Heat select
Used to set cool / heat select by remote controller
equipped with outdoor unit.
OFF (Factory set)
DS1-2
~DS1-4
ON
Not used Do not change the factory settings.
OFF (Factory set)
DS2-1
~4
ON
Not used Do not change the factory settings.
OFF (Factory set)
DS3-1,
2
ON
Not used Do not change the factory settings.
OFF (Factory set)
Caution
DIP switch Setting after changing the main P.C.Board(A1P) to spare parts P.C.B.
When you change the main P.C.Board(A1P) to spare parts P.C.B., please carry out the following
setting.
DIP Switch Detail
∗ If the DS1-4,DS2-1 setting(refrigerant classification) has not been carried out, error code
“UA” is displayed and unit can not be operated.
DS No. Item Contents
DS1-1 Cool/Heat change
over setting
ON The Cool/Heat change over setting is carried out by
COOL/HEAT changeover remote controller fitted to
outdoor unit.
OFF The Cool/Heat change over setting is not carried out
by COOL/HEAT changeover remote controller fitted
to outdoor unit.
DS1-2 Power supply
specification
ON 200V (mainly domestic Japan)
OFF 400V (mainly overseas)
DS1-3 Cooling only/Heat-
pump setting
ON Cooling only
OFF Heat-pump
DS1-4 New/previous unit
setting
ON
• Production after January 2004 :ON
OFF (Spare
parts PCB)
• Production before December 2003 :OFF
DS2-1 Domestic Japan or
overseas setting
ON
• Overseas :ON
OFF (Spare
parts PCB)
• Domestic Japan :OFF
DS2-2 HP setting
(Horse power)
Factory setting
of spare parts
PCB are all
OFF
DS2-3
DS2-4
1 2 3 4 1 2 3 4
DS1DS2
ON
OFF
ON
OFF
(
)
5 8 10 12 14 16 HP
DS2-2 OFF OFF ON OFF ON OFF
DS2-3 OFF ON ON OFF OFF ON
DS2-4 OFF OFF OFF ON ON ON
