SiE39-404 Troubleshooting by Remote Controller
Troubleshooting 169
Malfunction
code
Operation
lamp
Inspection
display
Unit No. Malfunction contents Page
Referred
Indoor
Unit
A0 999Error of external protection device 173
A1 999PC board defect, E
2
PROM defect 174
A3 999Malfunction of drain level control system (33H) 175
A6 999Fan motor (MF) lock, overload 177
A7 879Malfunction of swing flap motor (MA) 178
A9 999Malfunction of moving part of electronic expansion
valve (20E)
180
AF 879Drain level about limit 182
AH 879Malfunction of air filter maintenance —
AJ 999Malfunction of capacity setting 183
C4 999Malfunction of thermistor (R2T) for heat exchange
(loose connection, disconnection, short circuit,
failure)
184
C5 999Malfunction of thermistor (R3T) for gas pipes (loose
connection, disconnection, short circuit, failure)
185
C9 999Malfunction of thermistor (R1T) for air inlet (loose
connection, disconnection, short circuit, failure)
186
CJ 888Malfunction of thermostat sensor in remote controller 187
Outdoor
Unit
E1 999PC board defect 188
E3 999Actuation of high pressure switch 189
E4 999Actuation of low pressure sensor 190
E5 999Compressor motor lock 191
E6 999Standard compressor lock or over current 192
E7 999Malfunction of outdoor unit fan motor 193
E9 999Malfunction of moving part of electronic expansion
valve (Y1E~3E)
195
F3 999Abnormal discharge pipe temperature 197
F6 999Refrigerant overcharged 198
H3 879Malfunction of High pressure switch —
H4 999Malfunction of Low pressure switch —
H7 999Abnormal outdoor fan motor signal 199
H9 999Malfunction of thermistor (R1T) for outdoor air (loose
connection, disconnection, short circuit, failure)
200
J2 999Current sensor malfunction 201
J3 999Malfunction of discharge pipe thermistor (R31~33T)
(loose connection, disconnection, short circuit,
failure)
202
J5 999Malfunction of thermistor (R2T) for suction pipe
(loose connection, disconnection, short circuit,
failure)
203
Outdoor
Unit
J6 999Malfunction of thermistor (R4T) for heat exchanger
(loose connection, disconnection, short circuit,
failure)
204
J7 999Malfunction of header thermistor —
J8 999Malfunction of thermistor (R7T) for oil equalizing pipe.
(loose connection, disconnection, short circuit,
failure)
205
J9 999Malfunction of receiver gas pipe thermistor (R5T) 206
JA 999Malfunction of discharge pipe pressure sensor 207
JC 999Malfunction of suction pipe pressure sensor 208
L0 999Inverter system error —
L4 999Malfunction of inverter radiating fin temperature rise 209
L5 999Inverter compressor motor grounding, short circuit 210
L6 999Compressor motor coil grounding on short circuit —
L8 999Inverter current abnormal 211
L9 999Inverter start up error 212
