SiE39-404 Troubleshooting by Remote Controller
Troubleshooting 167
Mode
No
Function Contents and operation method Remote controller display example
40
Malfunction
hysteresis display
Display malfunction hysteresis.
The history No. can be changed with the
button.
41
Display of sensor
and address data
Display various types of data.
Select the data to be displayed with the
button. Sensor data
0: Thermostat sensor in remote controller.
1: Suction
2: Liquid pipe
3: Gas pipe
Address data
4: Indoor unit address
5: Outdoor unit address
6: BS unit address
7: Zone control address
8: Cool/heat group address
9: Demand / low noise address
43
Forced fan ON Manually turn the fan ON by each unit. (When
you want to search for the unit No.)
By selecting the unit No. with the button,
you can turn the fan of each indoor unit on
(forced ON) individually.
44
Individual setting Set the fan speed and air flow direction by each
unit
Select the unit No. with the time mode
button. Set the fan speed with the
button.
Set the air flow direction with the button.
45
Unit No. transfer Transfer unit No.
Select the unit No. with the button.
Set the unit No. after transfer with the
button.
46
This function is not used by VRV ll R410A Heat Pump 50Hz.
47
Hystory No: 1 - 9
1: Latest
Malfunction code
40
Unit 1
Malfunction code
2-U4
(VE007)
41
1 1
2 7
41
1 8
1
(VE008)
Address
Address typeUnit No.
Temperature °C
Sensor typeUnit No.
Sensor data display
Address display
43
Unit 1
(VE009)
44
1 3
(VE010)
Unit 1
Code
Fan speed 1: Low
3: High
Air flow direction
P0 - P4
45
0 2
Unit No. after
transfer
Present unit No.
Unit 1
Code
(VE011)
